Used in various medical institutions to suck the patient's airway secretions, operation when the suction in patients with exudate and flushing fluid.
One, product characteristics:
This machine adopts large-flow self-lubricating oil-free piston pump as a source of negative pressure, pumping speed, high vacuum rise fast, no oil pollution, can be removed from the pump body of the daily maintenance and management.
Swing rod in hand, push-pull freely; the attachment of the device box can be placed a foot switch and power line, mobile or storage more convenient.
Large diameter, large capacity storage bottle, easy to clean; equipped with seal ring stopper, good sealing performance and convenient opening.
Sensitive reaction, reliable overflow protection device, can prevent the liquid into the intermediate pipe.
Using transparent PVC suction hose, is easy to attract is observed when the fluid within the tubing; unique pipeline joint design, the pipeline connection is more convenient.
Suction pressure regulating valve can be controlled to attract needed negative pressure, negative pressure by the vacuum table to display.
Machine side is equipped with jacket and suspension type cleaning cup, before and after operation can be placed with suction tube.
Equipment using advanced design, compact structure, small; appearance, its configuration is more humanized.
In two, the main technical parameters:
Limit pressure value: = 0.09MPa ( 680mmHg )
Pumping speed: > 32L / Min
The liquid storing bottle: 2500mL x 2
Negative pressure regulating range: 0.02Mpa to limit the value of negative pressure
Noise: < 60dB ( A )
Source: AC220V 50Hz
Input power: 150VA
Packing size: 44.5cm * 39.5cm * 50cm
Net weight: 13kg
