Infusion pump, injection pump
JY-A2 Intelligent Infusion pump
|
Three-step Approach
|
Easy to Use
|
|
Pumping Mechanism
|
Curvilinear peristaltic
|
|
IV Sets
|
Compatible with IV sets of any standard
|
|
Flow Rate
|
1~1100 ml/h
|
|
Accuracy
|
Dedicated IV sets: ±3%; Standard IV sets: ±5%
|
|
Volume
|
1~9999 ml
|
|
KVO Rate
|
4 ml/h
|
|
Alarms
|
Occlusion, air-in-line, door open, end program, low pressure
|
|
Additional Features
|
Real-time shift totals, automatic power switching, mute button, bolus, system malfunction
|
|
Air-in-Line Detection
|
Ultrasonic detector
|
|
Infusion Management System (nurse call)
|
Optional
|
|
Power Supply, AC
|
110/230 VAC, 50/60 Hz, 20 VA
|
|
Battery
|
9.6V±1.6V, Rechargeable
|
|
Battery Life
|
3 hours at the 30 ml/h
|
|
Working Temperature
|
10-40℃
|
|
Relative Humidity
|
30-75%
|
|
Atmospheric Pressure
|
700-1060 hpa
|
|
Size
|
174*126*215 mm
|
|
Weight
|
2.5 kg
|
|
Safety Classification
|
Class Ⅰ, type CF
|
