Operation lamp
JY-A27 Cold light five hole operation shadowless lamp ( emergency power )
YD01-5 Emergency Cold Light Operating Lamp (on stand)
YD01 Series AC/DC Emergency cold light operating lamp meets the requirements of lighting for surgical operationsin special circumstances of where is no power supply. When there is power failure form elecctric grid or due to some other reasons , emergency power back up ctechnical data:an last 2hours continuously to make sure that the operation can be dne normally. It is fit for auxiliary lighting for medical examination on ears, nose, oral cavity,urinary system and gynaaecology.
YD01 Series AC/DC Emergency cold light operating lamp meets the requirements of lighting for surgical operationsin special circumstances of where is no power supply. When there is power failure form elecctric grid or due to some other reasons , emergency power back up ctechnical data:an last 2hours continuously to make sure that the operation can be dne normally. It is fit for auxiliary lighting for medical examination on ears, nose, oral cavity,urinary system and gynaaecology.
Technical Data:
1.llluminance: --------------------- ≥ 50000Lux,
2.Color temperature: --------------- 4000±500K
3.power supply voltage: ------------ ~220V/50-60Hz(110V/60Hz custom-made)
4.Rated Voltage of Bulb: ----------- 24V
5.Rated Power of Bulb: ------------- 25W
6.Input Power:---------------------- 150VA
7.Spot diameter:-------------------- 500MM
1.llluminance: --------------------- ≥ 50000Lux,
2.Color temperature: --------------- 4000±500K
3.power supply voltage: ------------ ~220V/50-60Hz(110V/60Hz custom-made)
4.Rated Voltage of Bulb: ----------- 24V
5.Rated Power of Bulb: ------------- 25W
6.Input Power:---------------------- 150VA
7.Spot diameter:-------------------- 500MM
8.Emergency time:------------------- 2 hours
9.Bulb:----------------------------- Cold light source or tungsten halogen bulb
9.Bulb:----------------------------- Cold light source or tungsten halogen bulb
