JY-A33 Cold light deep operation shadowless lamp (emergency power)
YD200 Emergency Cold Light Operating Lamp(deep)
YD200 AC/DC cold light operating lamp meets the requirements of lighting for surgical operationsin special circumstances or where there is no power supply. When there is power failure from electric grid or due to some other reasons, emergency power back op can last 2 hours continuously to make sure that the operation can be done normally. It is fit for auxiliary lighting for medical examination on ears, mose, oral cavity, urinary system and gynaecology.
Bulbs can halogen bulbs or LED.
Technical Data:
1.llluminance:-------------------- ≥50000Lux,
2.Color temperature: ------------- 4000±500K
3.power supply voltage: ----------- ~220V/50-60Hz (110V/60Hz custom-made)
4.Rated Voltage of Bulb: -------- 24V
5.Rated Power of Bulb: ---------- 50W
1.llluminance:-------------------- ≥50000Lux,
2.Color temperature: ------------- 4000±500K
3.power supply voltage: ----------- ~220V/50-60Hz (110V/60Hz custom-made)
4.Rated Voltage of Bulb: -------- 24V
5.Rated Power of Bulb: ---------- 50W
6.Input Power:------------------- 75VA
7.Spot diameter:----------------- 150MM
8.Bulb: ------------------------- Tungsten halogen bulb
8.Bulb: ------------------------- Tungsten halogen bulb
9.Emergency time:---------------- 2 hours
