JY-B2 Medical washing machine

Technology Date:

Developed film size : 3" x 14"~14" x 17"
(Applied for developing films of industrial inspection also )
Max. developing width : 430mm (17")
Channel volume : 10L
Developing speed : 90S~180S at option ( medical-use ),
2min ~ 12min at option (industrial inspection-use )
Developing temp. : 28--35 at option ( medical-use )
.......................... 24--35 at option(industrial inspection-use )
Developing capacity : 200pcs/h
.............................. 240 pcs/h(3" x 14")speed: 6min(4 lines)
Power source : AC220V , 50/60Hz
Power : 2.5kw
Net weight : 113kg
Gross weight : 180kg
Packing : 1340 x 840 x 1320 (L x W x H)

Product Characteristic:

Equipment Figure: New designed body and beautiful outlook. Taking films very expediently due films turn above.
Extra-Deep Tank Rolling Frame: Deep than wide is 3:1, this design make films very distinct clear.
Special Film-Sending Principle: Sending films by special crossing way and no touch guide systems design, no risk of films jamming or scratch.
Anti-oxidization Performance: Sealed chemicals circulation systems reduce touch area for chemicals and air.
Critical Parts: The rollers' material can resist high-temperate and crystallization. No change shape and swell for using long time.
Circuit Control: Microprocessor controls heating, automatic check and touch films, replenishing chemicals.
Energy-Saving: Keep sleep situation when no films need process after a while. Stop heating and rolling, then cut enter water. This can save energy for max limit.
